Mimaki LA-160W 62" Heat Assisted Laminator

Sold Out

Superior Finishing For Any Application

LA-160 laminator is a heat-assisted device with a maximum temperature of 140˚F (60˚C). This heat assistance improves overlaminate film adhesion, particularly to surfaces printed with UV ink, and reduces the potential for silvering effect created by pressure sensitive overlaminates.

62.2” maximum width
Fast throughput speeds
Easy to use, with all functions on one operations panel
Easy access to pressure handle and foot pedal
Take-up reel makes it easy for one person to operate the entire process
Designed to use with Mimaki Vision Laminate film and any of our roll-to-roll printers

Machine Includes:

Mimaki LA-160W 62" Laminator
Maximum Processing Width - 62.2″
Roller Diameter - 4.72"
Processing Thickness - 1.38"
Processing Speed - 0 to 295.3″ min (0 to 7500 mm/min)
Core Diameter - 3"
Preheating Time - About 30 minutes
Dimensions - 78.7″ x 21.7″ x 50.4″

LA-160W MANUAL
LA-160W Spec Sheet
